防爆填料函EX Cable Gland
您的位置：首页
> 产品中心
> 防爆填料函EX Cable Gland
详细描述
|
产品型号 |
螺纹 |
螺纹长度 |
电缆直径 |
接合长度 |
六角尺寸 |
|
BW-0 |
BW-0 |
10 |
12.6~16 |
23 |
22~25 |
|
BW-1 |
BW-1 |
10 |
15.9~19 |
26 |
27~32 |
|
BW-2 |
BW-2 |
10 |
20.6~26.5 |
29 |
35~40 |
|
BW-3 |
BW-3 |
10 |
26.5~33 |
32 |
42~48 |
|
BW-4 |
BW-4 |
15 |
34.9~40.5 |
36 |
52~60 |
|
BW-5 |
BW-5 |
15 |
44.6~51 |
45 |
65~75 |
|
BW-6 |
BW-6 |
15 |
57~67 |
50 |
82~94 |
|
BW-7 |
BW-7 |
15 |
68~79.5 |
60 |
96~110 |
|
BW-8 |
BW-8 |
15 |
74~83 |
65 |
100~115 |
|
BW-9 |
BW-9 |
15 |
82~91 |
69 |
/ |
|
BW-10 |
BW-10 |
15 |
93~100 |
88 |
/ |
适用范围：
1.1区、2区危险场所；
2.llA、I1B、IC类爆炸性气体环境。
产品特点：
1.采用黄铜、不锈钢制成；
2.具有快捷安装、安全可靠、防护性能好、防爆性能优越等特点；
3.适用于夹持和固定各种类型的钢芯、钢丝编织或带状铠装电缆，用于必须对电缆芯线部分隔爆及外壳气体密封达IP66的场所，防爆标志为：Exell的等效于|12GExell（欧标）Exdll等效于l12GExdll（欧标）
Applications：1.Hazardous:division182；2.Explosive gas atmosphere:class llA，IB，lIC.
Features：
1. It's made of copper or stainless steel material;
2. With reliable installation, good protecting and explosion-proof function;
3. Iso lating gasketing tube is suitable for clamping or fixing steel wire knit or anmour cable, its cable core and enclosure gassealing protection must be IP66, Ex-mark: Exe ll is equal to I12G Exe ll(Europen Standard)；Exe ll is equal to I12G Exe ll(Europen Standard)
